THROTTLE BODY
ITEM
I.D. No.
Bore size
Idle rpm
Throttle cable play

FUEL INJECTOR + FUEL PUMP+
ITEM
Fuel injector resistance
Fuel injector voltage
Fuel pressure of fuel pump
ELECTRICAL
ITEM
Ignition timing
Spark plug
Spark performance
Ignition coil primary peak
voltage
Ignition coil resistance
Spark plug cap resistance
Ignition coil secondary/ Spark
plug cap resistance/
Stator coil resistance
Magneto no-load
performance
Battery standard charging
voltage
Battery
Chapter 8 Information service Section 4 Service data
8-24
SPECIFICATION
1114111006300
28
1,400 ~ 1,600 rpm
0.5 ~ 1.0 mm (0.02 ~ 0.04 in)
FUEL INJECTOR + FUEL PUMP+
SPECIFICATION
11.4 ~ 12.6
Ω
at 20
℃
(68
℉
)
Battery voltage
Approx.3.46 ~ 3.67kgf/cm
2
(340 ~ 360kPa, 49.31 ~ 52.2
1
psi)
SPECIFICATION
BTDC 10°/
2,000 rpm and 28°/ 6,000 rpm
Type CR7E
Gap
0.7 ~ 0.8 (0.028 ~ 0.032)
More than 8 (0.32)8（0.32）
400 V and more400 V
Primary 0.52 ~ 0.64
Ω
Secondary
6.4 ~ 7.8
㏀
10 ㏀
16.4 ~ 17.8 ㏀
CKP Sensor Approx. 95
~ 125
Charging coil Approx. 0.3 ~
1.3
Over 60 V / 5,000 rpm
13.5 ~ 15.0 V / 5,000 rpm
Type
(6MF9)GEL
Capacity
12V
Chapter 8 Information service Section 4 Service data
NOTE
0.5 ~ 1.0 mm (0.02 ~ 0.04 in)
NOTE
)
1
Unit : mm (in)
NOTE
2,000 rpm and 28°/ 6,000 rpm
0.7 ~ 0.8 (0.028 ~ 0.032)
Ω
1st ⊕ -

㏀
2nd ⊕ -

spark plug
cap -

~ 125
Ω G - L
1.3
Ω Y - Y
(6MF9)GEL
12V
9Ah
