Chapter 8 Information service Section 4 Service data
8-23
EI SENSORS
ITEM
SPECIFICATION
MAP sensor input voltage
4.9 ~ 5.1V
MAP (Pressure function) sensor output voltage
Approx. 1.5V at. idle speed
1.5V
TP sensor input voltage
4.8 ~ 5.2V
TP sensor output voltage
Closed Approx. 0.6 ~ 1.0V
Opened Approx.4.0 ~ 4.6V
IAT sensor resistance
0.075~ 14.541 KΩ
[When Intake air temperature is -20 ~ 1℃ 20 ℃
(-40 ~ 2℉ 48 )][℉ -20℃
〜
120℃（-40℉
〜
248℉）]
IAT sensor resistance (each temperature)
-20
℃
(-40
℉
) Approx 14.541
㏀
-0
℃
(32
℉
) Approx 5.627
㏀
20
℃
(68
℉
) Approx 2.429
㏀
40
℃
(104
℉
) Approx 1.155
㏀
60
℃
(140
℉
) Approx 0.594
㏀
80
℃
(176
℉
) Approx 0.3277
㏀
120
℃
(248
℉
) Approx 0.1168
㏀
140
℃
(284
℉
) Approx 0.0749
㏀
Oxygen sensor heater voltage
Battery voltage
CLT sensor resistance
0.317 ~ 452.252 KΩ
[When Water temperature is-40 ~ 120 ℃ ℃
(-40 ~ 248 )][℉ ℉ -40℃
〜
120℃（-40℉
〜
248℉）
CLT sensor resistance [To ECU] (each temperature)[ECU]
-40
℃
(-40
℉
) Approx. 452.252
㏀
0
℃
(32
℉
) Approx.35.629
㏀
15
℃
(59
℉
) Approx. 16.222
㏀
30
℃
(68
℉
) Approx. 7.938
㏀
45
℃
(104
℉
) Approx. 4.137
㏀
60
℃
(140
℉
) Approx.2.272
㏀
90 (℃ 194 )℉
Approx. 0.781
㏀
120 (248 )℃ ℉
Approx. 0.317
㏀
