Configuring the Software Installing & Configuring PhotoPRINT Server
13-8 Sprinter User's Manual
Figure 13-11: The PhotoPRINT Server Matan Special Edition Main Screen
You now have to configure the 200 or 400dpi Setup.
! To configure the 200 or 400dpi Setup:
1. From the main screen, double-click the 200 or 400dpi icon, as
specified.
The S
ETUP PROPERTIES window appears, with the GENERAL tab open
(Figure 13-12).
400dpi already appears in the S
ETUP NAME text box (of this example).
Figure 13-12: Setup Properties Window – General Tab
2. In the MEDIA drop-down combo box, select your roll width, or, as we
recommend, select 90cm Roll.
3. Click the P
RINT tab.
The P
RINT tab appears (Figure 13-13, page 13-9).
Printing Window
RIPing window
Queuing Window
Display Window
To Next Page
