134 Appendix B: NTConfig Windows NT Embedded registry
Static or dynamic IP
Manually change some keys in the registry to set the IP
allocation mode and static IP address of your Matrox 4Sight
unit under Windows NT Embedded. These keys have been
initialized to default values and are available to all users on the
computer.
The IP allocation mode and static IP address setting can be
found in the following registry keys:
Registry Keys (INTEL
Ethernet)
Setup
HKEY_LOCAL_MACHINE\
SYSTEM\CurrentControlSet\
Services\E100E1\
Parameters\TcpIp\
IPAddress
Pass a multi-string
character-coded address.
For example, for the
address 192.168.54.109,
pass:
0x31 0x39 0x32 0x20 0x31
0x36 0x38 0x20 0x35 0x34
0x20 0x31 0x30 0x39 0x00
0x00.
HKEY_LOCAL_MACHINE\
SYSTEM\CurrentControlSet\
Services\E100E1\
Parameters\TcpIp\
SubnetMask
Pass a multi-string
character-coded address.
For example, for the subnet
255.255.255.0, pass:
0x32 0x35 0x35 0x20 0x32
0x35 0x35 0x20 0x32 0x35
0x35 0x20 0x30 0x00 0x00.
HKEY_LOCAL_MACHINE\
SYSTEM\CurrentControlSet\
Services\E100E1\
Parameters\TcpIp\
DefaultGateway
Pass a multi-string
character-coded address.
For example, for the
gateway 192.168.54.1, pass:
0x31 0x39 0x32 0x20 0x31
0x36 0x38 0x20 0x35 0x34
0x20 0x31 0x00 0x00.
