Matrox 4Sight - Page 175

Pin-outs of front panel connectors 175
17 GND -
Ground
18 GND -
Ground
19 VID_IN10 I
Video Input 10
20 VID_IN9 I
Video Input 9
21 NC -
Not connected
22 NC -
Not connected
23 VID_IN8 I
Video Input 8
24 USER1_OUT O
User Output
25 GND -
Ground
26 GND -
Ground
27 GND -
Ground
28 GND -
Ground
29 GND -
Ground
30 GND -
Ground
31 GND -
Ground
32 GND -
Ground
33 VID_IN11 I
Video Input 11
34 OPTOTRIG- I
Opto-isolated Trigger Negative Input
35 OPTOTRIG+ I
Opto-isolated Trigger Positive Input
36 NC -
Not connected
37 NC -
Not connected
38 GND -
Ground
39 USER1_IN I
User Input
40 VID_IN7 I
Video Input 7
41 VID_IN6 I
Video Input 6
42 GND -
Ground
43 VID_IN4 I
Video Input 4
44 VID_IN2 I
Video Input 2
