176 Appendix D: Technical reference
Matrox Meteor-II /Multi-Channel
Pin Signal I/O Description
1DC_OUTO
+12V Power Supply
2 HSYNC I/O
TTL Horizontal Sync
3GND-
Ground
4GND-
Ground
5GND-
Ground
6NC-
Not connected
7NC-
Not connected
8 USER2_OUT O
TTL User Output
9USER2_INI
TTL User Input
10 NC -
Not connected
11 VID2_IN1 I
Video Input 2 (Red)
12 NC -
Not connected
13 VID1_IN3 I
Video Input 1 (Blue)
14 GND -
Ground
15 VID1_IN1 I
Video Input 1 (Red)
16 DC_OUT O
+12V Power Supply
17 GND -
Ground
18 GND -
Ground
19 CLK_IN I
TTL Clock Input
20 TRIG I
TTL Trigger Input
21 NC -
Not connected
22 NC -
Not connected
23 EXP(2) O
TTL Exposure2 Output
24 USER1_OUT O
TTL User Output
25 GND -
Ground
26 GND -
Ground
27 GND -
Ground
28 GND -
Ground
29 GND -
Ground
30 GND -
Ground
31 GND -
Ground
