28
LOADING
THE
CONSUMABLE
S
7.
Make
sure
the
r
ibbon
is
not
slack.
If
the
ribbon
is
slack,
rotate
the
winding
core
toward
the
direction
of
the
arrow
to
remove
the
sl
ack
of
the
ribbon.
8.
Hold
the
ink
r
ibbon
case
as
illustrated
below
and
loa
d
it
complete
ly
.
9.
10.
Close
the
cassette
cover
unt
il
it
clicks.
Proper
loading
No
te
:
Make
sure
t
he
ribbon
is
no
t
slac
k
.
Pull
the
head
rel
ease
lever
(blue)
f
orwar
d
.
27
29
