267
Controls in detail
Useful features
The vehicle is equipped with a battery
charge socket. The socket allows for the
connection of the Maybach battery
charger* designed to charge the vehicle
consumer battery or to maintain the ex-
isting charge in the vehicle consumer
battery while the vehicle is parked and
not being driven for long periods of time
(on average approximately 3 weeks or
more). Not driving the vehicle for such
extended periods of time may cause the
charge in the vehicle batteries to drop.
The socket is located in the storage com-
partment on the left side of the trunk.
Only the Maybach battery charger*
should be connected to this socket.
1 Handle
2 Battery charge socket
3 Storage compartment
왘 Turn handle 1 90°.
왘 Swing the cover down.
왘 Connect the Maybach battery charg-
er* to battery charge socket 2. Fol-
low the separate operating
instructions for the Maybach battery
charger*.
i You can obtain the Maybach battery
charger* at any authorized Maybach Studio.
Check with an authorized Maybach Studio for
availability.
i If the battery for electrical consumers is
deeply discharged, it may take up to approxi-
mately 20 hours for the battery to be charged
using the Maybach battery charger*.
If faster charging is required, a standard bat-
tery charger may be needed. Using a standard
battery charger will require that you discon-
nect and remove the battery for electrical con-
sumers. For more information, see “Practical
hints” (컄 page 417).
The driver’s button is in the lower part of
the front center console under the cover
for the cup holders. Depending on vehi-
cle equipment configuration, the button
in the rear is either in the center console
or in the top of the center armrest.
Operating from the cockpit
Button in cockpit
1 To close the curtain
2 To open the curtain
Closing the curtain
왘 Briefly press button 1.
The curtain closes automatically.
왘 To stop the procedure, press the but-
ton again.
Battery charge socket Rear window curtain
