410
Practical hints
Replacing bulbs
Front turn signal and side marker lamp
bulb
왘 Turn the wheels so that the wheel at
the housing you need to work on is
turned inward.
This will provide easier access to the
lamp cover.
왘 Secure the vehicle from moving by
applying the parking brake and plac-
ing the gear selector lever in
position P.
왘 Make sure the engine and ignition
are turned off.
8 Cover in the wheel housing trim
왘 Turn cover 8 counterclockwise and
remove cover.
Front turn signal bulb
왘 Twist bulb socket 2 (컄 page 408)
counterclockwise and pull out.
왘 Push bulb into socket, turn counter-
clockwise and remove.
왘 Insert new bulb in socket, push in and
twist clockwise.
왘 Reinsert bulb socket 2 in lamp and
twist clockwise.
왘 Replace cover 8 (컄 page 410) and
turn it clockwise.
Side marker lamp bulb
왘 Twist bulb socket 3 (컄 page 408)
counterclockwise and pull out.
왘 Push bulb into socket, turn counter-
clockwise and remove.
왘 Insert new bulb in socket, push in and
twist clockwise.
왘 Reinsert bulb socket 3 in lamp and
twist clockwise.
왘 Replace cover 8 (컄 page 410) and
turn it clockwise.
1 Screws
2 License plate lamp
왘 Turn the exterior lamp switch to M
(
컄 page 142).
왘 Loosen both screws 1.
왘 Remove license plate lamp 2.
왘 Replace the bulb.
왘 Reinstall the license plate lamp 2.
왘 Retighten the screws 1.
Warning! G
Before reaching into the wheel housing,
make sure you have secured the vehicle
from moving by applying the parking
brake and placing the gear selector lever in
position P. Otherwise, the vehicle may
move unexpectedly. Unexpected vehicle
movement while you are working near the
wheel housing may cause serious personal
injury and/or an accident.
License plate lamp
