CRIMP DATA ANALYZER
CDA10
REV.01
6. USE
6.1 SWITCH
The equipment is dependent on the machine; therefore, it is necessary to use the press switch to
operate or switch off both. The switch has two positions:
• OFF position (O), in which the power supply is disconnected
• ON position (I), in which the power supply is connected.
6.2 ELECTRICAL CIRCUIT
The equipment is designed to be used in conjunction with the press machine. The sensing unit
contains the circuit that detects and analyses the crimping force and processes its profile. The unit is
connected directly to the press control unit, takes its power and disables it when monitoring failed
crimping.
Further clarifications on the electrical connections and the components used are available on the
relative wiring diagram and in the relative section.
Since all machine movements are controlled by electrical and/or electronic
signals, it is advantageous if these signals are controlled by qualified
personnel
.
