CRIMP DATA ANALYZER

CDA10

REV.01

6.5 MACHINE USE PROCEDURES

6.5.1 INITIAL CHECKS

The operator must check the following before starting the machine:

• Make sure that all power sources are properly connected to the respective power supply

networks.

• Make sure that there are no foreign bodies in the radius of action of the machine.

• Verify correct functioning of the safety devices present (emergency buttons, etc.).

• Check that the machine is not in maintenance or cleaning status.

• Make sure that the switch is in the ON position (I).

• Verify that the press ready status light is on.

• Make sure that the load cell is correctly configured with the settings for use with equipment.

6.5.2 CONNECTING POWER

Before starting the machine:

• Connect the electricity.

• Set the switch on the electrical box of the press to the ON position (I).

6.5.3 OPERATING MODE

The control unit acquires and analyses the crimping force curve profiles. Whenever incorrect

crimping is detected, the machine emits a beep and disables the press until the operator intervenes.

6.5.4 SWITCHING OFF THE MACHINE

To switch off the machine, set the switch on the electrical box of the press to the OFF (0) position.
