MAINTENANCE SERVICE MANUAL NUMBER 22
Page 1B-72 90-860074--1 FEBRUARY 2002
23. Remove seawater pump impeller for storage:
a. Remove seawater pump cover mounting screws, and remove cover and gasket.
b. Ease impeller off pump shaft with two screwdrivers.
c. Reinstall cover for storage.
NOTE: Pump shown removed for visual clarity only.
71366
a
b
c
d
e
Typical
a-Seawater Pump Housing
b-Cover Screws
c-Cover
d-Gasket
e-Impeller
IMPORTANT: It is recommended that others be informed to NOT operate the engine.
24. Place a CAUTION TAG at instrument panel and in engine compartment stating that the
seawater pump is out - Do NOT operate engine.
CAUTION
Sterndrive unit should be stored in full DOWN / IN position. Universal Joint bellows
may develop a set if unit is stored in raised position and may fail when unit is
returned to service.
25. Place sterndrive unit in the full DOWN / IN position.
