TROUBLESHOOTING SERVICE MANUAL NUMBER 22
Page 1C-30 90-860074--1 FEBRUARY 2002
Cooling System (continued)
Cause Special Information
13. Obstruction in cooling system such as
casting
flash, sand, rust, salt, etc.
13. Refer to water flow diagram for engine
type being serviced
14. Engine water circulating pump
defective
18. Heat exchanger core or tubes plugged
15. Also refer to Engine Overheats
(Mechanical)
Mechanical
Cause Special Information
1. Engine rpm below specifications at
wide-open-throttle (engine laboring)
1. Damaged or wrong propeller; growth
on boat bottom; false bottom full of
water
2. Incorrect injection pump timing 2. Injection pump timing too far advanced
or retarded
3. Seawater pump impeller slipping
4. Exhaust restriction
5. Valve timing off 5. Jumped timing chain, or gears
improperly installed
6. Insufficient lubrication to moving parts
of engine
6. Defective oil pump, plugged oil
passage, low oil level
To Next Page
