INSTRUMENTATION
SERVICE MANUAL NUMBER 22
90-860074--1 FEBRUARY 2002 Page 4D-3
NOTICE
For information and procedures on Troubleshooting refer to SECTION 1C.
Identification
Gauges
QUICKSILVER INSTRUMENTS
NOTE: One of three distinct series of Quicksilver gauges may be installed. Aside from
different gauge face appearances and styling, the back of the gauges and wiring
connections are different.
72965
Typical QSI Series
77333
Typical Admiral Series (Back of Flagship Series Similar)
Panels
QUICKSILVER INSTRUMENTS
73546
a
b
Typical Quicksilver Instrumentation
a-Gauges
b-Engine System Monitor Panel
To Next Page
