ENGINE MECHANICAL
SERVICE MANUAL NUMBER 22
90-860074--1 FEBRUARY 2002 Page 3A-127
Installation
FRONT MAIN BEARING
1. Align oil passage with hole of new bearing.
70313
a
b
a-Oil Passage
b-Bearing Hole
2. Place new bearing on Puller/Installer Tool 91-801333508 as shown. Tool will install
bearing to the correct depth. Oil passage MUST BE aligned.
NOTE: To aid installation retain bearing halves on tool with a rubber band or similar.
70402
a
b
a-Tool 91-801333508
b-Bearing Halves (On Tool)
