MAINTENANCE

SERVICE MANUAL NUMBER 22

90-860074--1 FEBRUARY 2002 Page 1B-51

Filling

1. Add Power Trim and Steering Fluid or SAE 10W-30 engine oil to bring oil to proper level.

2. Install reservoir cap.

77348

a-Reservoir Fill Neck

b-Reservoir Cap
