ENGINE MECHANICAL

SERVICE MANUAL NUMBER 22

90-860074--1 FEBRUARY 2002 Page 3A-153

MIE (Inboard) Transmission Mounts

27035

Transmission Mount Components

a-Base

b-Housing

c-Bushing

d-Trunion (Pin)

e-Snap Ring

f-Bracket

g-Clamping Bolt

50533

27035

Standard Mount Position Alternate Mount Position

a-Mount Bracket

b-Bolts
