ENGINE MECHANICAL
SERVICE MANUAL NUMBER 22
90-860074--1 FEBRUARY 2002 Page 3A-17
Engine Specifications (continued)
NOTICE
UNIT OF MEASUREMENT: mm (in.)
Connecting Rods
Description Measurement
Weight
1
1250 grams (44.09 ounces)
1
:
All service connecting rods are median weight and class.
Connecting Rod Crank Pin Bore
Description Measurement
Inner Diameter 57.563 - 57.582 (2.2662 - 2.2670)
Maximum Allowable Wear or Taper 0.02 (.0008)
Connecting Rod Bushings
Description Measurement
Piston Pin Outer Diameter 29.990 - 29.996 (1.1807 - 1.1809)
Connecting Rod Bushing Inner Diame-
ter
30.035 - 30.050 (1.1824- 1.1830)
Minimum and Maximum Clearance 0.039 - 0.060 (.0015 - .0023)
Pistons
Description Measurement
Diameter -
Standard
Class A 93.925 (3.6978)
Flywheel
Description Measurement
Runout - Face 0.10 (.004)
Runout - Bore 0.10 (.004)
