MAINTENANCE SERVICE MANUAL NUMBER 22
Page 1B-58 90-860074--1 FEBRUARY 2002
Alternator Belt
NOTE: On some engines it may be necessary to remove other drive belts to gain access
to a particular belt during replacement. Refer to appropriate sections for information
concerning individual drive belts and proceed accordingly.
CAUTION
Before removing the seawater pump hoses, close the seacock, if equipped. If boat
is not equipped with a seacock, remove and plug the seawater inlet hose to prevent
a siphoning action that may occur, allowing seawater to enter the boat.
1. Close the seacock, if equipped. If boat is not equipped with a seacock, remove and plug
the seawater inlet hose.
2. Remove seawater pump inlet and outlet hoses.
78310
b
a
Typical
a-Inlet Hose
b-Outlet Hose
3. Loosen alternator mounting and tensioning bolts.
4. Pivot the alternator to loosen belt.
5. Remove old belt.
6. Install new belt.
To Next Page
