MAINTENANCE
SERVICE MANUAL NUMBER 22
90-860074--1 FEBRUARY 2002 Page 1B-59
7. Pivot the alternator. Adjust belt deflection to be 5 mm (3/16 in.) measured at midpoint
between the pulleys on the longest belt span.
8. Torque tensioning and mounting bolts 28 Nm (21 lb-ft).
73521
b
74301
a
c
Typical
a-Deflection: 5 mm (3/16 in.)
b-Tensioning Bolt
c-Mounting Bolt
9. Install the seawater pump inlet and outlet hoses.
10. Open the seacock, if equipped. If boat is not equipped with a seacock, remove the plug
and connect the seawater inlet hose.
