CHARGING SYSTEM SERVICE MANUAL NUMBER 22
Page 4B-8 90-860074--1 FEBRUARY 2002
Charging System Components
The alternator system consists of the alternator, battery, the ignition switch and the wiring
which connects these components.
NOTE: The wire color codes vary between models and are not shown. Refer to SECTION
4E Wiring Diagrams for color code information.
75420
a
b
c
d
e
f
g
h
Typical
a-Battery Meter
b-Ignition Switch
c-Harness Plug and Connector
d-Alternator
e-Circuit Breaker
f-Starter Motor
g-Ground Stud
h-Battery
