ENGINE MECHANICAL
SERVICE MANUAL NUMBER 22
90-860074--1 FEBRUARY 2002 Page 3A-5
Torque Specifications (Continued)
Description Nm lb-in. lb-ft
Main Bearing Carrier Halves Bolt
1
M10x1.5 44.1 32
Main Bearing Carrier Locating Hollow Bolt M14x1.5 53.9 39
Inboard (MIE) Drive Plate 72 53
Sterndrive MCM Coupler 30 22
Oil Drain Plug M22x1.25 78.5 57
Oil Pan Screws M6x1.0 12.7 112
Oil Pressure Relief Valve Assembly 53.9 39
Oil Pump Screw M8x1.25 27.5 20
Oil Pick-up Tube Screw 11 97
Oil Adapter / Thermostat Housing Fitting 60 44
Power Steering Pump Mounting Bolt 21 15
Rocker Arm Support Flanged Nut M8x1.25 34 25
Timing Gear Cover
M6x1.0 10.8 95
M8 10.8 95
Valve Cover M6x1.0 11.5 101
Vibration Damper (Balancer) M10x1.5 83.4 61
Water Manifold M6x1.0 11.8 104
Water Pump M8x1.25 24.5 18
Water Pump Pulley M8x1.25 27.5 20
1
: Bolts may be used a maximum of 3 times within the prescribed torque limits.
