Mercury D4.2L D-Tronic

ENGINE MECHANICAL SERVICE MANUAL NUMBER 22
Page 3A-24 90-860074--1 FEBRUARY 2002
4. Without loosening, torque each side bolt as indicated.
Engine
Sequence Torque
D2.8L Side Bolts 11-12-13-14-15-16-17-18 90 Nm (66 lb-ft)
D4.2L Side Bolts 15-16-17-18-19-20-21-22-23-24-25-26 90 Nm (66 lb-ft)
15
16
17 18
19
20
21 22 23 24 25 26
77113
11 12 13 14
15 16 17 18
77114
b
a
Side Bolt Torque Sequence Diagram
a-D2.8L D-Tronic Engine
b-D4.2L D-Tronic Engine
