ENGINE MECHANICAL

SERVICE MANUAL NUMBER 22

90-860074--1 FEBRUARY 2002 Page 3A-97

5. Remove the idler gear If complete engine disassembly is required, or if idler gear is worn

or damaged.

IMPORTANT: Mark retaining screws for reassembly in their original locations.

70292

a-Idler Gear

b-Retaining Screw With Lockwasher
