ENGINE MECHANICAL

SERVICE MANUAL NUMBER 22

90-860074--1 FEBRUARY 2002 Page 3A-119

7. Mark position of rear main bearing carrier in relation to block.

70302

a-Rear Main Bearing Carrier

b-Cylinder Block

c-Reference Mark

8. Remove the screw locking thrust plate to crankshaft.

70302

a-Locking Screw

b-Thrust Plate
