ENGINE MECHANICAL
SERVICE MANUAL NUMBER 22
90-860074--1 FEBRUARY 2002 Page 3A-145
STERNDRIVE (MCM ) MODELS (CONTINUED)
1-Continuity Wire
2-Washer
3-Screw
4-Rear Portion of Flywheel Housing - Sterndrive (MCM)
5-Screw
6-Lockwasher
7-Grease Fitting
8-Bravo Coupler Assembly
9-Screw (6)
10 - Washer (6)
11 - Second Stage Coupler
12 - Screw and Washer
13 - Turbocharger Bracket
14 - Flat Washer and Lockwasher
15 - Turbocharger Mounting Screw (2)
16 - Screw, Flat Washer and Lockwasher (9)
17 - Flywheel Ring Gear
18 - Thrust Plate / Guide Ring O-ring Seal
19 - Set Screw and Thrust Plate / Guide Ring
20 - Flywheel With Ring Gear
21 - Flywheel Bolt (6)
22 - RPM Speed Sensor
23 - Wave Washer and Allen Head Screw
24 - O ring Seal
25 - Starter Stud, Washer, and Nut
26 - Flywheel Housing
27 - Lockwasher (6 mm)
28 - Screw, M6 x 1 x 20 (6)
29 - First Stage Coupler
30 - Two-Stage Coupler Assembly
Description
Part Number
A Clean SAE 30W Engine Oil Obtain Locally
B Loctite 271 Thread Locker 92-809819
