STARTING SYSTEM
SERVICE MANUAL NUMBER 22
90-860074--1 FEBRUARY 2002 Page 4A-5
Starting System Components (continued)
1-Ignition (Start) Switch, (Start/Stop)
2-20 Ampere Fuse
3-Remote Control Neutral Safety Switch [MCM (Sterndrive)]
4-Instrument/ Extension Harness Connector at Electrical Box
5-Circuit Breaker
6-Circuit Breaker
7-Start Relay
8-Main Relay
9-ECM / Fuel System Harness Connector at Electrical Box
10 - ECM
11 - Battery
12 - Starter
13 - Electronic Shut-Off Solenoid
1.
Wire routing on Sterndrive (MCM) engine and instrument harness with Neutral
Safety Switch located in remote control.
2.
Wire routing on Inboard (MIE) engine and instrument harness with Neutral
Safety Switch located on transmission.
3.
Shown for clarification of start and stop circuits.
