INSTRUMENTATION
SERVICE MANUAL NUMBER 22
90-860074--1 FEBRUARY 2002 Page 4D-27
EARLY MODEL WIRING HARNESS CONNECTIONS
75305
76057
75871
a
c
d
75884
b
e
f
g
1 2 3
456
Sterndrive Shown, Inboard Similar
a-Second (2nd) Station Instrumentation
b-Second Station Instrument Harness
c-Primary Station Instrument Harness
d-Primary (MAIN) Station Instrumentation
e-Y-Box (Harness)
f-Extension Harness
g-To Engine
To Next Page
