WIRING DIAGRAMS
SERVICE MANUAL NUMBER 22
90-860074--1 FEBRUARY 2002 Page 4E-31
INBOARD (MIE) - SECOND STATION INSTRUMENTATION - PAGE 2 OF 2
1-Voltmeter Gauge
2-Tachometer Gauge
3-Water Temperature Gauge
4-Oil Pressure Gauge
5-Wires Not Used On This Model.
6-Engine System Monitor Panel
7-Malfunction Indicator Lamp (Check Engine)
8-Coolant High Temperature
9-Oil Pressure Warning Lamp / Low Gear Lube Monitor Level Lamp
10 - Charge Indicator Lamp
11 - Preheat Indicator Lamp
12 - Panel Lights/Audio Warning Test Switch
13 - Stop Switch
14 - Start Switch
15 - Spare Wires (Optional Hour Meter Gauge)
16 - Audio Warning Horn - Oil
17 - Audio Warning Horn - Temperature
18 - Instrument Harness Connector (Deutscht)
19 - Fuel Gauge Wires Not Used
20 - Connector Without Relay
21 - Connector Jumper
22 - 20 Amp Fuse
23 - Audio Warning Delay Relay (During Pre-Heat)
24 - Diode Pack
25 - Neutral Start Safety Circuit - Refer To Transmission Neutral Start Safety Switch
Circuit On Inboard Models
1.
Keep wires separated. Not used on this model. Tape each wire separately with
at least two layers of electrical tape.
2.
Spare wire.
INSTRUMENT / EXTENSION HARNESS CONNECTOR
NOTE: Refer to Item Number 18 from preceding page.
Terminal
Letter
Wire Color
Code
Terminal
Letter
Wire Color
Code
Terminal
Letter
Wire Color
Code
A YEL/RED H TAN R YEL/WHT
B RED J LT BLU S ORN
C TAN/BLK K BLU/TAN T BRN/WHT
D BLK L BLK/YEL U (NOT USED)
E GRN/RED M YEL V (NOT USED)
F TAN/BLK N PPL/ORN X RED/YEL
G PPL P GRY W BRN
To Next Page
