FUEL INJECTORS SERVICE MANUAL NUMBER 22

Page 5C-4 90-860074--1 FEBRUARY 2002

Tools

Bosch

EFEP60H Nozzle Tester

0 681 200 502

Description:

Robert Bosch Corporation

2800 South 25th Avenue

Broadview, IL 60153

Mailing Address:

P.O. Box 4601

North Suburban, IL 60197

Phone: (312) 865-5200

74442

Lubricants / Sealants / Adhesives

Description Part Number

30W Engine Oil Obtain Locally
