EDI DIAGNOSIS

SERVICE MANUAL NUMBER 22

90-860074--1 FEBRUARY 2002 Page 5E-101

HARNESS VIEWS

75300

Instrument Harness And Connector

a-Early model 16 Pin Standard Connector

b-Late Model 21 Pin Deutscht Connector

75395

Engine Harness And Electrical Box
