CLOSED COOLING SYSTEM
SERVICE MANUAL NUMBER 22
90-860074-1 FEBRUARY 2002 Page 6B-5
Torque Specifications
Description Nm lb-in. lb-ft
Engine Water Circulating Pump Screw 30 22
Thermostat Housing Cover 16 132
Heat Exchanger Bracket / Thermostat Housing 30 22
Water Pump Pulley Screw 8.5 72
Water Manifold 10 84
Upper Heat Exchanger End Cover Bolt 14-15
120 -
132
Lower Heat Exchanger End Cover Bolt 12-14
108 -
120
Lubricants / Sealants / Adhesives
Description Part Number
2-4-C Marine Lubricant With Teflon 92-802859A!
Special Lubricant 101 92-802865A1
Perfect Seal 92-34227--1
Loctite Master Gasket 92-12564--2
Loctite Pipe Sealant with Teflon Obtain Locally
Tools
Special Tools
Description Part Number
Cooling System Cleaner 91-814825
Fleetguard Restore - CC2610 Obtain Locally
Tools
Description Part Number
Pink Litmus Paper Obtain Locally
Thermostat Tester Obtain Locally
Heat Exchanger Cleaning Brush Obtain Locally
Cooling System Pressure Tester Obtain Locally
