CLOSED COOLING SYSTEM
SERVICE MANUAL NUMBER 22
90-860074-1 FEBRUARY 2002 Page 6B-9
Heat Exchanger / Coolant Tank and Related Components (continued)
1-Screw, M6x78 mm (5)
2-Lockwasher (6)
3-Hose Clamp
4-Thermostat Housing To Heat Exchanger Hose
5-Engine Lifting Eye
6-Screw, M10 x 35 mm (1-3/8 in.) Long (3)
7-Lockwasher (3)
8-Port Side Heat Exchanger Bracket
9-Water Circulating Pump Bypass Hose
10 - Thermostat Housing And Starboard Heat Exchanger Bracket
11 - Hose Clamp
12 - Gasket
13 - Thermostats - 2 Different Temperatures
14 - Thermostat Housing Cover
15 - Stud, M6 x 75 mm (3 in.) Long (1)
16 - Lockwasher
17 - Engine Cover Mount Threaded Spacer/ Nut (1)
18 - Thermostat Housing To Heat Exchanger Hose
19 - Screw with Lockwasher, M8 x 100 mm (3-15/16 in.) Long (2)
20 - Screw with Lockwasher, M8 x 60 mm x (2-23/64 in.) Long (2)
21 - Pressure Cap
22 - Heat Exchanger / Coolant Tank
23 - Hose Clamp (2)
24 - Circulating Pump-to-Heat Exchanger Hose
25 - Drain Screw and Sealing Washer
26 - Engine Model Decal
27 - Heat Exchanger To Bracket Clamps (2)
28 - Engine Water Circulating Pump
Description
Nm lb-in. lb-ft
A Heat Exchanger Bracket / Thermostat Housing Bolt 30 22
B Thermostat Housing Cover Bolt 16 132
C Heat Exchanger End Cover Bolt Upper 14-15
120 -
132
D Heat Exchanger End Cover Bolt Lower 12-14
108 -
120
