ZF / HURTH TRANSMISSIONS
SERVICE MANUAL NUMBER 22
90-860074--1 FEBRUARY 2002 Page 8A-9
Filling
If transmission fluid level is low, fill with specified transmission fluid.
1. Remove dipstick.
2. Fill transmission through dipstick tube.
3. Replace dipstick and recheck level.
77564
a
a-Dipstick Tube
Changing
1. Clean the exterior of the transmission around the fluid filter assembly.
2. Use a 6 mm allen wrench and remove the fluid filter assembly from the transmission by
turning counterclockwise and pulling at the same time.
27666
