Controlling a rotary control 169
PRO6 Live Audio System
Owner’s Manual
>> To assign a control to the I zone
Open the Assignable Controls window and do one of the following:
•In the assignable controls section (I zone) on the control surface, press and hold
down an I zone assign/unassign button. Operate the desired control; if necessary
navigate its channel to the control surface first.
• At the master bay GUI screen, open the
Assignable Controls window and
select the control you want to assign
from the three panels at the bottom of
the window (see “About the Assignable
Controls window” on page 168). For
example, choose the compressor ratio
control of input channel 34. Then click
one of the overlying assign/unassign
buttons (as shown right).
• An alternative method is to press and hold down an I zone assign/unassign button in
the assignable controls of the control surface. Then, on the GUI (maser bay screen),
click the desired control.
>> To unassign a control in the I zone
1 In the Assignable Controls window on the GUI, click Unassigned in the far left
panel (bottom of window).
2 Click the desired I zone assign/unassign button.
>> To manually set the tap time of an effect
1 Assign the desired effect’s delay time parameter to an I zone control. (Choose
the Effects in the left panel and then the desired channel and delay time
parameter from the other panels.)
2 Tap the assign/unassign button of the I zone control (just as you would the Tap
button of the effect) to achieve the desired tap time.
The PRO6 measures the interval between taps. It
uses the most recent taps to calculate the average
tap time, which is constantly updated according to
each subsequent tap. This value is displayed on the
effect’s front panel in the appropriate Range field
and is also indicated by the control knob immediately
left.
