504 Appendix O: Parameters Affected By Stereo Linking
XL8 Live Performance System
Owner’s Manual
Note: The compressor and gate sidechains of stereo paired channels are always linked
such that they ensure the same amount of gain reduction is applied to both channels.
10 freq control knob Compressor sidechain frequency
11 WIDTH pushbutton Compressor sidechain width: 2 Oct, 1 Oct or
0.3 Oct
12 ON/[GTE] switch Gate on/off
13 threshold control
knob
Gate threshold
14 release control knob Gate release
15 attack control knob Gate attack
16 ratio/range/[range]
control knob
Gate range
17 hold control knob Gate hold
18 IN switch Gate sidechain in/out
19 freq control knob Gate sidechain frequency
20 WIDTH pushbutton Gate sidechain width (unlabelled) selector: 2 Oct,
1 Oct and 0.3 Oct
Item Control Parameter
