11. Work surface
See chapter 5.1 for the available grid plates.
Maximum capacity of the work surface: 40Kg distributed.
Refer to chapter 1.3.3 – Ventilation.
Ventilation is applied on the work surface in 2 distinct parts that cannot be excluded:
-Work surface area (downdraft) in blue.
-Area on the panel behind the work surface (backdraft) in green.
12. Magnetic holder bar
Metal objects, such as tweezers and blades, can be attached on the bar.
13. Shelf
It can be mounted on the right or on the left, depending on the position of the shower tap.
It is shown in the previous photo.
Measurements: WxD 45x9cm
Maximum capacity: 1Kg
14. Tap with clinical lever
It is always mounted in a central position.
If turned to the left it dispenses cold water, to the right it dispenses hot water.
