Work with UltraGROSS with the safety shield closed. Operator protection is only
guaranteed with the shield closed.
There is a compartment for the safety shield sensor, shown in the figure below, on the objects holder surface
(5) on the left.
9. Safety shield with camera openings
The figure shows the safety shield in shatterproof glass.
The following figure shows the three positions available for the camera (only for initial code 180), at the
openings on the safety shield. The openings are closed by a polycarbonate panel that must be removed in
presence of the camera.
For initial code 150, only the opening in position 2 is present.
