20. Used fixative drain (only for letter D- 2X if double letter D in code)
By default, it can be mounted on the right under the fixative dispenser described above.
The following figures show the funnel that can be kept covered when not used.
The drain hole is covered by a removable filter to protect the specimens .
When only one cover is applied (figure 2), it can slide back and forth.
Milestone recommends keeping it closed when not used.
For the VIRCHOW model, refer to chapter 2.5.7.
21. Front baffle
Used to improve the front ventilation flux and to limit turbulence.
22. Rear baffle
Used to improve the ventilation flux and to limit turbulence.
23. Set up for grinder button
Please refer to chapter 5.10.
