5.10. Waste Grinder
CODE 109249
Suitable only for UltraGROSS systems at 230-240Volt 50/60Hz
Power supply 220-240V ~ 50/60 Hz
Single stage grinding technology
0.75 hp induction motor
Average absorption 380 W
1425 RPM
Pneumatic switch
Shipping weight 11.6Kg
Grind chamber capacity: 1180ml
Drain connection 1 ½ ‘’
The following figure indicates the overall dimensions (in millimeters):
Environmental conditions:
Altitude: up to 2000m
Operating temperature: from 15°C (59 °F) to 30°C (86 °F)
Relative humidity: 10°C - 80%, non-condensing
5.10.1. Installation specifications
This chapter indicates the maximum possible sizes for correct assembly with the supplied cables.
A Schuko power socket 40cm above the ground is required to install the Waste disposal
unit, in the position indicated in the following figures, between the washbasin and the left
leg of UltraGROSS.
