141
5.17. Conveyor Kit
It is possible to connect the two air outlets of the unit to a single outlet using this optional part CODE 109254.
It includes: conveyor kit, 2 m flexible pipe Ø 200 mm with two metal straps.
Inlet 2x Ø160 mm.
Outlet 1x Ø200 mm.
Coupling material: PVC.
Dimensions: 600x530x230mm.
Weight: 5.8Kg.
5.18. Keyboard support
CODE 109170
You may couple this optional part along the entire front baffle.
Material: AISI 304 stainless steel.
Surface dimensions where the keyboard is placed:
390 mm x160 mm.
It must be fixed to the wall with the 4 dedicated holes.
Use specific fixing systems based on the type of wall used.
