UltraGROSS
MM182-001 – Operator Manual
142
5.19. Inlet water pressure regulator
This optional part CODE 102726U must be installed on the water inlet if the pressure of the laboratory’s water
system is higher than the parameters indicated in chapter 2.5.8.
It must be installed on both water inlets.
Inlet: 1/2’’ female.
0-6 bar pressure gauge included.
5.20. Foot Tap with hoses and support
This optional part CODE 102958 allows you to dispense hot or cold water with your feet.
It includes: three 3 m flexible pipes, ½’’ female inlets, ½’’ male outlets.
The pedal inlets are connected to the hot and cold water of the laboratory, the pedal outlet must be connected
to the unit (cold water inlet). Plug the hot water inlet of the unit.
When present, the clinical lever of the tap on the work surface must remain open and turned to the cold water
position.
Pressing the blue pedal: continuous dispensing of cold water.
Pressing the red pedal: continuous dispensing of hot water.
Simultaneously pressing red and blue pedals: continuous dispensing of mixed water.
Pressing yellow pedal: release water closure.
Maximum pressure 6 bar.
Fluid temperature MIN: +2 °C MAX 52 °C.
