UltraGROSS
MM182-001 – Operator Manual
21
Unit control terminal
Characteristics: TFT 8” color display
Resolution: 800x600 pixel
Resistive Touchscreen
Memory: 4GB
CPU dual core 1.33GHz
Windows 10 IoT Enterprise LTSB™
- I/O-Interface: 2 USB 2.0 ports
- Dedicated Milestone software with icon-based graphic interface
MacroPATH terminal
(only for models with letter T – see chapter 1.3.1)
- CPU: Intel
®
Core™ i7 Processor 2.6 GHz
- RAM: 8GB DDR-4
- Hard disk: 500GB (SSD)
- Touch-pen: USB cable, tip of 1.5mm diameter
- Screen: 19" TFT LCD 1280X1024 16.7M Color, IP 65 front panel
- Fanless
- Wi-Fi 802.11 A/B/G with Bluetooth v4.1 (*)
(*) subject to restrictions of use according to local radio frequency regulations to be checked before enabling
this function.
- Dimensions: LxHxD 470.5 x 415.2 x 75.6mm
- Weight: 7.4Kg
- PC power supply: 18V DC 5.55A MAX
- Operating System: Windows 10 Enterprise™ 64 bit (Microsoft Windows 10 and Microsoft Word are Microsoft
Corporation registered brands) – LTSC 2019
- I/O available (see images below):
A) 2x RS-232/422/485 Serial ports
B) 2x Gigabit Ethernet LAN ports (RJ-45)
C) 6x USB 2.0 ports
D) 2x USB 3.0 ports
E) 1x HDMI (max resolution 4096x2304@24Hz)
F) 1x DP Display port (max resolution 4096x2304@60Hz)
G) 2 X built-in 2W speakers
H) Audio Mic-in 3.5mm jack input
I) Audio 3.5mm jack output
J) Power supply inlet
K) Reading lights
L) Equipotential terminal
It is necessary to connect the unit to a fume extraction system.
Maximum air flow rate for each outlet: 1100m³/h ± 100m³/h.
The system must allow for a flow rate of at least 1200m³/h.
For code 180 the flow rate at 0.5 m/s front is 450 ± 50m³/h.
For code 180 the flow rate at 0.7 m/s front is 600 ± 50m³/h.
For code 150 the flow rate at 0.5 m/s front is 400 ± 50m³/h.
For code 150 the flow rate at 0.7 m/s front is 550 ± 50m³/h.
