6-WORKINGOPERATIONS

2.Removethetankcap(1)tollthetankwiththedesired

uid.Replacethecapafterlling.Eachtankholds

189L(50USgal).

RAIL17SP01071AA12

3.Draintheinjectiontanksbyaccessingthebottomside

ofthetank(1).Removethedrainplug(2)anddrain

thetankuidintoasuitablecontainer.

Replacethedrainplugafterdrainingtheuidfromthe

tank

Repeatforallinjectiontankspresent.

RAIL17SP01073AA13

6-38
