Mindray Resona R9 Exp User Manual

4 - 38 Operator’s Manual
4 Setup
Worklist Setting
DICOM service setting for Worklist is described as follows:
MPPS Preset
MPPS setting items are described as follows:
NOTE:
Set the MPPS service as the default when using the MPPS.
Item Description
Device After you set the server (s) in DICOM Server Setting screen, the name
(s) will appear in the drop-down list, select the name of the Worklist
server.
Service Name Default is server-Worklist, and it can be modified.
AE Title Application Entity title. It is consistent with that of the Worklist server.
Port DICOM communication port, 104 by default. The port should be
consistent with that of the Worklist server port.
Maximum Retries Reserved feature.
Interval Time(Sec) Reserved feature.
Timeout(Sec) Refers to time after which the system will stop trying to establish a
connection to the service.
TLS Transport Layer Security. Select whether to encrypt the data during
network transportation.
Strategy Name Set the DICOM strategy.
Remove Attribute Set what DICOM element(s) that will not be used in worklist query.
Item Description
Device After you set the server (s) in DICOM Server Setting, the name (s) will
appear in the drop-down list, select the name of the MPPS server.
Service Name Default is server-MPPS, and it can be modified.
AE Title Application Entity title. It should be consistent with that of the MPPS
server.
Port DICOM communication port, 104 by default. The port should be
consistent with that of the MPPS server.
Maximum Retries It starts retrying if it fails to send DICOM task to the server. The retry
entry times should be this value.
Interval Time(Sec) Reserved feature.
Timeout(Sec) Refers to the amount of time after which the system will stop trying to
establish a connection to the service.
TLS Transport Layer Security. Select whether to encrypt the data during
network transportation.
