7 - 16 Operator’s Manual
7 3D/4D
Capturing preparation does not support the measurement.
Image Saving
• Image saving:
– In the 3D Review mode, press <Save> (with user-defined saving function) to save the
current image and volume data to the patient information management system in the set
format.
– Save cine: in 3D viewing mode, press the user-defined save key to save CIN-format clip
to the hard drive.
• Image review:
Open an image file to enter the image review mode. In this mode, you can perform the same
operations as what you can in review mode.
7.4 Color 3D
Color 3D imaging provides more visualized flow information, especially in heart and kidney
application, which helps in observing cardiovascular diseases.
7.4.1 Basic Procedures for Color 3D
1. Enter into color 3D image acquisition preparation status:
a. Obtain a feasible Power/Color image with the volume probe.
b. Press knob to enter 3D/4D image acquisition preparation status.
2. Set the acquisition, displaying related parameters, select acquire mode.
3. Press <Update> to begin image acquisition.
4. After the acquisition is completed, the system enters into image view status; you can perform
operations like image edit and storage.
5. Save image as necessary.
7.4.2 Operation Controls
Display
You can choose to display only color images or gray scale images, or to mix them.
Priority
To determine color information displayed on gray scale images.
Threshold
To eliminate color noise and motion artifacts.
Affects MPR as well as VR.
Opacity
To set the transparency value for VR rendering.
Smooth
To smooth the Color image and erase artifacts by time averaging.
