16 Patient Data Management
Operator’s Manual 16 - 5
To exit the image analysis
• Press <Freeze> to exit and enter the real-time scan status.
• Press [Return] to exit from the image analysis to the Review status.In image analysis status,
the selected image is displayed on the screen, and the thumbnails of the same exam are
displayed on the thumbnail area, you can turn pages using the buttons on the right side of the
thumbnail.
16.1.10Sending Image File
Data saved this way can only be reviewed on the PC and cannot be restored to the ultrasound
system.
Perform the following procedure:
1. Do one of the following to bring up the “Send To” screen:
– In the main screen, select a stored image thumbnail and click on the upper right corner
of the image.
– In the iStation screen, select a stored image and click .
– In Review screen, click to send patient data to an external memory device.
– In the Review screen, select a image and click [Send To].
2. Select from the destination:
NOTE:
• If the transferred AVI file cannot be played normally on PC, please try to transfer the
multi-frame cine file in MP4 format and try Send To function again, or use a VLC
media player.
• You can select whether to hide patient info: if “Default Info” is selected, the patient
name is hidden after backup; if “Custom Info” is selected, the system prompts a
message requiring you to input the patient name, which will be displayed after backup.
Item Description
USB/iStorage For external memory devices (e.g. USB memory devices, DVD
recorder) or network storage server, you can set:
• PC format transfer.
• DCM format transfer
•Cine Zoom Mode.
• Export the report or the report format.
• Hide patient information.
DICOM/Print/eGateway Select the DICOM Storage, Print server or eGateway server.
MedTouch/MedSight Send the image to MedTouch/MedSight as necessary.
NOTE:
The file sent to MedTouch/MedSight is transferred into PNG
format, and the cine file is transferred into AVI format.
To Next Page
