7 3D/4D
Operator’s Manual 7 - 43
4. Press <Update> to start capturing volume CEUS image.
During the acquisition, a progress bar is displayed to indicate the acquisition progress.
The system saves the single frame image when the acquisition is completed and enters the
review status of 3D image. Tap [Contrast]/[Tissue] on the touchscreen. The image on the main
monitor is switched between the contrast image and the tissue image.
It is available to perform operations on VOI setting, parameter adjustment, image editing,
image comment, image measure and image saving, etc. in image review. see “7.3.3 Static 3D
Image Viewing” for details.
5. Repeat step 2-4 to obtain the contrast images if necessary.
7.20 Smart Scene 3D
• Smart Scene 3D is not available in Smart 3D mode.
• This feature is available only under GYN, OB2 or OB3 exam mode.
In 3D/4D acquisition preparation status, this feature can adjust ROI size and position automatically
and activate appropriate render modes according to the recognized anatomical structure of some
organs.
For OB2/OB3 exam mode, spine, brain, long bone and face can be recognized. For GYN exam
mode, endometrium can be recognized.
Perform the following procedure:
1. Enter 3D/4D acquisition preparation status.
2. Tap [Smart Scene 3D] under 3D/4D Scenario Setting to enable the feature.
– If necessary, select the desired organ type manually.
– If necessary, tap [Refresh] to reset the ROI.
– If necessary, adjust the ROI size and position manually.
3. Press <Update> to begin 3D/4D acquisition.
