14 - 8 Operator’s Manual
14 Measurement, Comments and Body Mark
14.4 Body Mark
After powering off, the system will clear all comments on the image.
The Body Mark feature is used for indicating the exam position of the patient and transducer
position and orientation.
You can preset the system configured general body marks for each exam mode. The system
supports the import of user-defined body marks.
14.4.1 Touch Screen Display in Body Mark
The body mark touch screen displays the settings for the current mode:
Library
Rotate the knob under the [Library] button on the touch screen or press the knob to switch the body
mark library, the corresponding body marks are shown on the left.
Page-turning
If there is more than one page, slide the touch screen to turn the page.
Save Probe
Under the condition that the probe mark direction and position is determined for the current adding
body mark, tap [Save Probe] to save the current direction and position for the probe mark of the
current body mark.
14.4.2 Adding Body Mark
Perform the following procedure:
1. Press <Body Mark> to enter the Body Mark status, tap [Library] to select the body mark
category.
2. Adding Body Marks:
– Adding the body mark using the trackball and <Set> key.
Move the cursor onto the desired body mark to highlight your choice, and press <Set> to
add the body mark.
– Adding the body mark using the touch screen.
Tap the desired body mark on the touch screen directly.
3. To adjust the probe position and orientation marker.
– Use the trackball to place the probe marker at the correct position.
–
Rotate <Angle
> to adjust the
mark’
s direction.
– Tap [Save Probe] to save the current direction and position for the probe mark of the
current body mark.
4. Press <Set> to confirm the position and orientation of the probe marker and exit the body mark
mode.
14.4.3 Moving Body Marks
You can move the body mark graphics to any desired position within the image area.
