10 Physiological Unit Signal
Operator’s Manual 10 - 5
2. Tap [Physio] or press the user-defined <Physio> key. Tap [PCG] on. The PCG wave appears.
3. Press the different mode buttons to change the imaging mode. Adjust the parameter to obtain
the optimized image.
4. Adjust [PCG Gain] and [PCG Smooth].
5. Freeze the image and the curve, and then review them.
6. Tap [Physio] or press the user-defined <Physio> key to disable PCG wave. Then exit the PCG,
and unplug PCG sensor.
10.3.2 PCG Sensor Cleaning
NOTE:
• Disconnect the sensor with the ultrasound system before cleaning the PCG sensor.
• Do not rub PCG sensor hard in case of the damage to the sensor.
Clean the PCG sensor after each time use in case of the cross-infection.
• The check after the exam of general patient:
Wipe the sensor with soft cloth dipping with medicinal alcohol, and then air dry the senor or
clean the sensor with dry cloth.
• The check after the exam of patient with cutaneous infection:
Use the cover for the sensor. The cover should be against the appearance of the acoustic
window.
Use the appropriate cover.To order the cover, contact:
CIVCO Medical Instruments Co.
102 First Street South, Kalona, IA 52247-9589 USA
Tel: 1-319-656-4447
E-mail: info@civco.com
http://www.civco.com
10.4 Parameter Description
The physio parameters are described as follows:
3 Pulmonary valve auscultation area 4 Mitral auscultation area
Type Parameter Description
ECG
parameter
ECG Source Select ECG source.
Gain Set the amplitude of the trace.
Position Set the vertical position of the both traces on the image
display.
Speed Change the speed of the physio trace.
T1 Set the delay time T1 in Single trigger or Dual trigger.
T2 Set the delay time T2.
Interval Set the time interval for Timer.
Invert Invert the display.
